Trek Fuel EX 9.8 GX AXS T-Type Gen 6
1 / 2
Trek

Trek Fuel EX 9.8 GX AXS T-Type Gen 6

SKU: 5300903UPC: 768682681183
Type: Mountain Bike
SAVE 44%
$3,999.93$7,149.99
Secure checkoutReturns accepted within 30 days
VisaMastercardAmexDiscoverStripe

Description

Fuel EX 9.8 GX AXS is a trail-charging machine that packs a punch on the singletrack with a lightweight and stiff carbon fiber frame that damps jarring vibrations, and holds its own when you pick a line. It's loaded with the tech you want, like SRAM GX AXS wireless shifting for remarkably reliable shifting under load, plus a 150mm front and 140mm rear FOX Performance suspension package that smooths the roughest trails. It's all topped off with carbon Bontrager wheels that shed weight and keep tracking precise.
  • Fuel EX Gen 6 gives you 140/150mm of travel and slack, adjustable geometry for an extra capable ride, plus, in-frame storage on all models — even alloy
  • It comes equipped with light and stiff carbon wheels that make quick work of technical terrain and keep you on your line when things get hairy
  • You get the latest technology in SRAM's GX AXS 12-speed transmission for precision shifting — even under load, plus a FOX Performance suspension package
  • With the adjustable angle headset (angled cups sold separately) and Mino Link, you can choose from six different geometry configurations
  • We expanded our size range to ensure a better fit for all riders, and use the best-fitting wheels for each frame size: XS frames get 27.5˝ wheels, S frames get to choose between 27.5˝ or 29˝, and sizes M and up get 29˝ wheels



Tech Specs

FrameOCLV Mountain Carbon, internal storage, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, guided internal routing, magnesium rocker link, 34.9mm seat tube, ISCG 05, 55mm chainline, BSA 73, downtube guard, shuttle guard, ABP, UDH, Boost148, 140mm travel
ForkFox Performance 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel
ShockFox Performance Float X, 2-position damper, 185mm x 55mm
Wheel FrontBontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 27.5''
Wheel RearBontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle, 27.5''
TireBontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 27.5x2.50''
Tire PartBontrager TLR sealant, 6oz
Rim StripBontrager TLR
Skewer RearBontrager Switch thru axle, removable lever
ShifterSRAM AXS POD
Rear DerailleurSRAM GX Eagle AXS, T-Type
CrankSRAM GX Eagle, T-Type, DUB, 30T, 55mm chainline, 170mm length
Bottom BracketSRAM DUB MTB Wide, 73mm, BSA threaded
CassetteSRAM Eagle XS-1275, T-Type, 10-52, 12 speed
ChainSRAM GX Eagle, T-Type, 12 speed
BrakeSRAM CODE Bronze 4-piston hydraulic disc // SRAM CODE Bronze 4-piston hydraulic disc
Brake RotorSRAM CenterLine, 6-bolt, round edge, 180mm
SaddleBontrager Arvada, austenite rails, 138mm width // Verse Short Comp, steel rails, 145mm width
SeatpostBontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 345mm length // Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 310mm length
Handlebar Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5mm handlebar rise, 820mm width, 0 degree stem rise, 35mm stem length
HeadsetIntegrated cartridge bearing, 1-1/8'' top, 1.5'' bottom, angle adjust cup compatible
GripsBontrager XR Trail Elite, nylon lock-on
BatterySRAM AXS battery pack (with charger)

Product Identifiers

BrandTrek
TypeMountain Bike
SKU5300903
UPC768682681183
MPN5300903

Internal Storage

Internal frame storage makes it easy to ditch the pack and still carry your ride essentials.

Internal Storage

Active Braking Pivot

Active Braking Pivot allows our engineers to tune how the suspension reacts to acceleration and braking forces independently. That means you get more confident control when you need it most.

Active Braking Pivot

Slack or steep, the choice is yours

Install angle adjust headset cups (sold separately) to tweak the 64.5-degree head tube angle a degree steeper or slacker to your liking — all without impacting your bottom bracket height.

Slack or steep, the choice is yours

Adjust the sus for full send

Adjust leverage rate with just a flip of a chip. Ride it in the Less progressive setting for a plusher feel perfect for rugged trails with square-edge bumps. Flip it to More progressive when you're hitting big features and don’t want to bottom-out, or when you want to run a coil shock.

Adjust the sus for full send

Size-specific stays

Size-specific chainstays provide balanced handling to keep the ride nimble for smaller riders and improve front wheel traction on climbs for taller riders.

Size-specific stays

Business in the front, party in the back

Craving the nimble ride of 27.5˝ wheels but don’t want to sacrifice the speed of a 29er? No need to choose. Fuel EX is mullet-ready, just throw Mino Link in high, toss on a 160mm fork, and get ready to party.

Business in the front, party in the back

Geometry

B B Drop2.1
B B Height33.7
Chainstay Length43.4
Eff Seat Tube Angle78.9°
Eff Top Tube51.6
Frame Reach40.4
Frame Size LetterXS
Frame Stack57.2
Head Angle64.9°
Head Tube Length9.5
Offset4.4
PositionHigh
Seat Tube36
Seat Tube Angle71.2°
Standover71.9
Trail11.9
Wheelbase114.4
Wheel Size27.5"
